    This page documents a history of a specific aircraft. The details provided vary from aircraft to aircraft and are dependent on the research and amount of data uploaded to the Aerial Visuals database.

    Airframe Family: Bell 209 / AH-1 Cobra
    Latest Model:AH-1F Cobra
    Last Military Serial:70-15993 US
    Construction Number:20937
    Compressed ID:Bell AH-1F sn 70-15993 US cn 20937
    Latest Owner or Location:Russell Military Museum, Russell, Illinois

    EDIT THE HISTORY HERE    		 If you can add to the history or would like to submit a correction please use the editor to do so.

    UPLOAD A PHOTO    		 If you have a photo of this airframe to share then use the photo upload tool.
    The Airframes Database depends on user contributions to stay current.
    If you have any news about this airframe or photos which you would like to share please do so
    by using the links above.
    The more you and others share the better the database becomes!

    Dates

    Event

    Constructed as an AH-1G-BF by Bell at Fort Worth, Texas, USA.

    Circa 1971

    Taken on Strength/Charge with the United States Army with s/n 70-15993.

    Circa 1981

    Converted to an AH-1S (Modernized).

    1988

    Redesignated as AH-1F.

    By October 1997

    Transferred to 1st Squadron, 18th Cavalry Regiment (ARNG), Azusa, CA.

    By 21 May 2001

    Assigned to Fort Drum, NY for storage.

    By December 2002

    To Kenosha Military Museum, Kenosha, WI.

    22 May 2004


    Photographer: Glenn Chatfield
    Notes: At the Kenosha Military Museum on a very rainy day. The museum moved south across the Illinois border to become Russell Military Museum.

    October 2007

    To Russell Military Museum, Russell, IL.
    View the Location Dossier

    16 August 2008


    Photographer: Glenn Chatfield
    This dossier is waiting for review by an editor.This airframe dossier is based on
    unreviewed imported data.
    If you can verify the documented history or add to it with additional text and/or photos please feel free to do so by using the upload tool and the history editor.
    Credits
     Data for airframe dossiers come from various sources. The following were used to compile this dossier...
    Print Sources
     Military Aircraft Serials of North America by S. Mitchell and A Eastwood
    U.S. Army Aircraft Since 1947 by Stephen Harding GC
    U.S. Military Out of Service 2010 by Andy Marden
    Internet Sources
     Aerial Visuals - The Locator by Mike Henniger, Senior Editor
    United States Military Services Serial Number Lists by Joe Baugher
    Individual Contributors
     Glenn Chatfield
    Mike Henniger
